Tech Notes
FEATURES
Chassis: Fiber composite
Drive: Four wheel shaft, universal driveshafts
Motor: 370 brushed
Radio: 2.4GHz pistol grip with electronic steering trim control,
waterproof 32 oz-in steering servo, and 3-channel micro receiver
ESC: Waterproof, programmable with three driver profiles;
Sport Mode, Race Mode and Training Mode
Built-in two-stage low-voltage detection for LiPo batteries
Body: ProGraphix, trimmed and painted
Differentials: Gear type with steel ring and pinion gears
Battery: Traxxas Power Cell NiMH 6-cell stick pack w/Traxxas High-
Current connector, compatible with Traxxas iD chargers
Battery Charger: 110V AC powered wall charger with Traxxas High
Current battery connector, 350mAh charging rate
Shocks: Oil-filled, adjustable
Front Suspension: Fully independent
Steering: Bellcrank type with servo saver
Tires: SST grippy, soft compound, aggressive tread pattern
Wheels: Five spoke, 1.38" (35mm) outer diameter
Bumpers: Front and rear flexible composite plastic
INCLUDES
RTR Latrax SST Stadium Truck with Brushed Motor, 2.4GHz Radio, ESC,
NiMH Battery, Charger, 4 AA Batteries, Painted Body, Instructions
10T Pinion Gear, 60T Spur Gear
REQUIREMENTS
Track and maintenance equipment
SPECIFICATIONS
Vehicle;
Length: 12.16" (309mm)
Front and Rear Track: 6.73" (171mm) outer edges of wheels measured
side to side
Weight with Battery: 26.06oz (739g)
Weight without Battery: 20.16oz (572g)
Overall Height: 4.61" (117mm)
Wheelbase: 6.44" (163.5mm)
Ground Clearance: 0.59" (15mm)
Internal Gear Ratio: 2.5:1
Overall Drive Ratio: 15:1 (Stock, Out-of-box)
Gear Pitch: 0.5 Mod.
Front and Rear Shock Length: 2.36" (60mm)
Battery Tray Dimensions: 4.0 x 1.4 x 0.71" (102mm x 35mm x 18mm)
Body;
Length: 12.2" (310mm)
Width: 6.8" (174mm)
Height: 3.7" (95mm)
