TRX2250

Servo - Waterproof Digital High-Torque 330 Coreless Metal Gear

Product Info | Replacement Parts | Fits What?
TRAXXAS

TRX2250
Servo - Waterproof Digital High-Torque 330 Coreless Metal Gear
By TRAXXAS
$119.99 CAD
FREE SHIPPING over $99
Details »
Order Quantity:
Click to Enlarge
click to enlarge

More like this... Servos Digital
But only from... TRAXXAS
All items from... TRAXXAS


 Inventory Status Legend
StockStock availability for on-line ordering
1
$119.99
Warehouse ?
StockStock availability for pick up
1
$119.99
Warehouse ?
0
$119.99
Store - Stratford ?
0
$119.99
Store - Edmonton ?
0
$119.99
Store - Mississauga ?
1
$119.99
Store - Ottawa ?
0
$119.99
Store - Oshawa ?
0
$119.99
Store - Halifax ?
This live feed information is to be used as a general guide to current inventory. There is no guarantee of availability.
Best selling related parts, options and upgrades...
Gear Set Metal (For 2250 2255 Servos)
$43.99

Servo Case Aluminum (Blue-Anodized) (Middle) 2250
$28.99

Servo Case Plastic (Top Middle Bottom)/Gaskets/Har...
$17.99

SPECIFICATIONS
Standard
Size Class:
Digital Coreless
Type:
Steering Servo
Application:
Dual
Bearing:
6.0 - 7.4 v
Voltage Range:
3.7 kg-cm (330 oz-in)
Torque @ 6.0V:
0.19 sec/60°
Speed @ 6.0V:
25 Tooth
Output Spline:
Metal
Geartrain:

FEATURES
  • Factory fit for drop-in installation into Traxxas Models
  • Fully waterproof, not "water resistant"
  • Compatible with Traxxas Stability Management (TSM)
  • 330 oz-in torque at 6.0V
  • 0.19 sec/60° at 6.0V
  • Metal gears
  • Dual ball bearings
  • Coreless motor technology
  • Aluminum center case

** Not suitable for X-Maxx application **

High-Torque 330 Blue Servo
The Traxxas High-Torque 330 Blue servo combines maximum steering authority with a long list of high-performance features. The servo utilizes full metal gears, dual ball bearings, and an aluminum center section for added heat dissipation. A powerful coreless motor provides 330 ounce-inches of torque for the most demanding applications.* The High-Torque 330 servo is fully waterproof, not just “water resistant” and drops into most 1/10 Traxxas vehicles for that perfect factory fit.

The Power to Perform
With over 2.5 times more torque than the standard #2075 servo, the High-Torque 330 provides noticeably faster turning speed and works great with TSM equipped vehicles. Traxxas High-Torque servos are the perfect upgrade for high-demand applications like Unlimited Desert Racer, Slash, Stampede, or almost any 1/10 Traxxas vehicle requiring extreme performance. Replace the E-Revo's dual servos with a single #2250 for lighter weight, more torque, and lightning-quick steering response. Elevate your steering performance to the next level with the High-Torque Blue 330 servo.

Waterproof Not "Water Resistant"
Traxxas knows the difference between “water resistant” and waterproof. Traxxas High-Torque servos are completely waterproof to give you the freedom to run when you want, where you want. Power through streams and bogs without fear while trucks with “water resistant” servos are stuck on the sidelines.
