ST GS-45 ABC RC w/Muffler
RESOURCES
Manual/Diagram
|
|
||||
 |
||||
|
||||
 |
|
|
Discontinued
|
 |
More like this... 2-C Glow Aircraft Motors .40 to .49
But only from... SUPER TIGER
All items from... SUPER TIGER
But only from... SUPER TIGER
All items from... SUPER TIGER
StockStock availability for on-line ordering
StockStock availability for pick up
This live feed
information is to be used as a general guide to current inventory. There is no guarantee of
availability.
Best selling related parts, options and upgrades...
|
|||||||||||||
SPECIFICATIONS
.46 cu in
Displacement:
0.860 in
Bore:
0.787 in
Stroke:
2,500 - 16,000
RPM:
1.45 HP @ 16,000 rpm
Output:
13.2 oz
Weight (w/o muffler):
18.5 oz
Weight (with muffler):
9.5 x 6, 10 x 6
Prop Range:
1/4 - 28
Crankshaft Threads:
FEATURES
- Improved design for stronger performance—yet still very economical
- Silent muffler substantially reduces noise levels without power loss
- Features Schnuerle porting, ball bearings and a lightweight cast head
- Includes Muffler and Glow Plug
The Super Tigre GS-45 is one of the most popular engines in use today and boasts new timing and a 10% power increase over the previous S-45K model. The engine is of ABC construction and features: precision ball bearings at the front and rear of the crankshaft for smooth operation and long life; Schnuerle porting for increased power; lightweight cast head which improves power to weight ratio; expanded volume muffler which can be bolted on the engine at virtually any angle; and true hard chrome plating, ABC construction, with proven advantages in high performance engines.
