SPMXAE1200HV

Avian 200A HV Smart Brushless ESC 6S-14S

Product Info | Fits What?
SPEKTRUM

SPMXAE1200HV
Avian 200A HV Smart Brushless ESC 6S-14S
By SPEKTRUM
$669.99 CAD
FREE SHIPPING over $99
Details »
Order Quantity:
Click to Enlarge
click to enlarge

More like this... Aircraft Electronic Speed Controls (ESC)
But only from... SPEKTRUM
All items from... SPEKTRUM


 Inventory Status Legend
StockStock availability for on-line ordering
0
$669.99
Warehouse ?
StockStock availability for pick up
0
$669.99
Warehouse ?
0
$669.99
Store - Stratford ?
0
$669.99
Store - Edmonton ?
0
$669.99
Store - Mississauga ?
0
$669.99
Store - Ottawa ?
0
$669.99
Store - Oshawa ?
0
$669.99
Store - Halifax ?
This live feed information is to be used as a general guide to current inventory. There is no guarantee of availability.
SPECIFICATIONS
Air
Type:
200 A
Max Continuous Current:
300 A
Max Burst Current:
Brushless
Compatible Motors:
6 - 14 cells
LiPo Cells:
6.0/7.4/8.4 V
BEC Voltage:
25 A (peak)
Max BEC Output:
376 g
Weight:
89 mm
Length:
50 mm
Width:
36 mm
Height:
IC5
Battery Connector:

FEATURES
  • Smart All-in-One Telemetry: This ESC system provides valuable telemetry data without any extra accessories. It reports information such as RPM, temperature, battery voltage, and capacity in real time.
  • Fast 32-bit ARM M4 Processor: The powerful processor ensures efficient performance and responsiveness.
  • Smart ESC Programming Box: Easily program your ESC using this dedicated box.
  • SmartLink USB Updating and Programmer Application: Update and configure your ESC via USB.
  • Throttle Stick Programming: Adjust settings directly from your transmitter.
  • Over-Current Protection: Guards against excessive current draw.
  • Automatic LiPo Low-Voltage Cutoff: Prevents over-discharging your battery.
  • Thermal Protection: Keeps the ESC safe during high-temperature conditions.
  • Failsafe Protection: Ensures reliable operation even in critical situations.
  • Developed by Spektrum Engineers: Designed in collaboration with the industry’s leading ESC manufacturer.
  • Compact and Installation-Friendly: Easy to fit into most applications.
  • No Soldering Required: Ready to install out of the box.
  • Efficient Heat Dissipation: Features an aluminum heat sink for optimal cooling.
  • Dual BEC Power Connectors: Provides power to your servos and receiver.
  • Firmware Updatable: Keep your ESC up-to-date using the Smart ESC Programming Box and SmartLink PC application.
  • High Heat-Resistant IC Connectors: Compatible with EC connectors for seamless integration.

Like every component in the Spektrum Smart ecosystem, Avian Smart ESCs combine "plug-and-play" simplicity with the ability to communicate with other Smart electronics — together, creating the best-performing RC system for your aircraft imaginable.

Avian Smart Air ESCs do much more than regulate power. They function like a virtual engineer inside your model, providing a direct path to the vital operating data you need to reach peak performance. Avian Smart Air ESCs give you an extra layer of confidence that your electronics are all operating at their best.

With Avian Smart Air ESCs, you'll be better connected to your aircraft than ever before — without installing extra components that all work independently of each other. You won't need extra wires, modules, or links. An Avian electronic speed control provides a one-wire solution for obtaining telemetry data such as current, voltage, cell balance, temperature and RPM.

Avian ESCs not only gather the data but also send it to your transmitter in real time, instead of only storing it for after-run study. You're able to adjust settings as needed to boost performance on the go. The Avian Smart single-wire telemetry solution has been tested for quality and performance by the best brands in RC. Their verdict? Smart technology is both simpler and superior!

In The Box

(1) Spektrum Avian Smart 200A HV Brushless ESC
(1) Spektrum Smart Sticker Sheet
(1) Product Manual

Needed to Complete

Spektrum Aircraft Receiver
Spektrum Smart Technology LiPo Battery
Spektrum Transmitter
