HS-785HB Karbonite Sail Winch (3.5 Turns) Servo 1.4/183oz
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
 |
|
|
|
click to enlarge
|
StockStock availability for on-line ordering
StockStock availability for pick up
This live feed
information is to be used as a general guide to current inventory. There is no guarantee of
availability.
SPECIFICATIONS
59 mm
Length:
29 mm
Width:
50 mm
Height:
110 g
Weight:
Karbonite
Geartrain:
4.8 - 6.0 v
Voltage Range:
11 kg-cm (153 oz-in)
Torque @ 4.8V:
1.68 sec/60°
Speed @ 4.8V:
13.2 kg-cm (183 oz-in)
Torque @ 6.0V:
1.38 sec/60°
Speed @ 6.0V:
FEATURES
- 3-Pole Ferrite Motor
- Dual Ball Bearing
The HS-785HB sail winch servo with its large drum wheel has 3 1/2 revolutions of travel for hauling in even the largest of sails. With its dual ball bearing supported output shaft the HS-785HB will provide years of reliable service.
