HDZ3110

HDZero Whoop 2S-6S Digital Video Transmitter 32.5x32.5mm

Product Info
HDZ3110
HDZero Whoop 2S-6S Digital Video Transmitter 32.5x32.5mm
By HD ZERO
$69.99 CAD
FREE SHIPPING over $99
Details »
Order Quantity:
Discontinued
Click to Enlarge
click to enlarge

More like this... Digital Video Transmitters
But only from... HD ZERO
All items from... HD ZERO


 Inventory Status Legend
StockStock availability for on-line ordering
0
$69.99
Warehouse ?
StockStock availability for pick up
0
$69.99
Warehouse ?
0
$69.99
Store - Stratford ?
1
$69.99
Store - Edmonton ?
0
$69.99
Store - Mississauga ?
0
$69.99
Store - Ottawa ?
0
$69.99
Store - Oshawa ?
0
$69.99
Store - Halifax ?
This live feed information is to be used as a general guide to current inventory. There is no guarantee of availability.
FEATURES






The HDZero Whoop VTX is a digital HD 720p 60fps video transmitter capable of delivering up to 200mw on 5.8GHz. It works with the Shark Byte RX5.1 goggle module to transmit video, and with a remote controller to wirelessly control the parameters for the transmitter and camera.



Specifications

Model:  HDZero Whoop

Frequency: 5.8G

Resolution Default:  1280*720@60fps

RF power:  25mw/200mw

RF Connector:  U.FL

Interface:  4 lane MIPI CSI YUV422

Video Connector: 20 Position 0.30mm Pitch

Size:  32.5mm x 32.5mm x 7mm

Weight:  5.4g

Power:  410mA@12V

Power Input:  7-26V(2S-6S)

Mounting:  25.5mm*25.5mm M2 clearance hole

Includes

1 - HDZero Whoop VTX

4 - Power/ Uart Cables
