SPECIFICATIONS
12 A
Max Continuous Current:
2-4 cells
LiPo Cells:
5-12 cells
NiMH/NiCd Cells:
2 V
BEC Voltage:
13 g
Weight:
32 mm
Length:
24 mm
Width:
10 mm
Height:
FEATURES
Safety Arming Feature: Regardless of the throttle stick position, the motor will not spin after battery is connected.
Throttle Calibration: Throttle range can be configured to provide the best throttle linearity. Fully compatible with all available transmitters.
Programmable Items:
Brake Setting: brake enabled / brake disabled.
Battery Type: Li-xx(Li-ion or LiPo) / Ni-xx(NiMh or NiCd).
Low Voltage Protection Mode (Cutoff Mode): Gradually reduce the output power / Cutoff the output power.
Low Voltage Cutoff Protection Threshold (Cutoff Threshold): low / medium / high.
Start Mode: normal / soft / very soft.
Timing: low / medium / high.
Reset: reset all programmable items to their default settings.
Full Protection Features: Low voltage cutoff protection / Over-heating protection / Throttle signal lost protection.
Advantages:
Military standard capacitor with extremely low resistance decreases unwanted RF noise during flying.
Extreme low resistance PCB helps create super current endurance capability.
Microprocessor uses a separate voltage regulator IC, with great anti-jamming capability.
Compatible with Hobbywing's Program Card (purchase separately)
