SuperG ELRS 2.4G Nano TX Module - Grey
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
|
|
||||
 |
||||
|
||||
 |
|
|
|
click to enlarge
|
But only from... BETAFPV
All items from... BETAFPV
- Groundbreaking Gemini Dual-Frequency Diversity Transmitter: The Gemini ushers in a new era of dual-frequency capabilities for ELRS, revolutionizing the way signals are transmitted.
- Dual 1W Transmit Power for Enhanced Performance: With dual 1W transmit power, experience a significant boost in signal strength, expanded transmission distances, and a substantial increase in remote control range.
- Gemini Mode for Unwavering Signal Stability: When paired with existing true diversity receivers, activating the Gemini mode ensures steadfast signal stability even in complex radio environments, providing a reliable connection.
- Precision Engineering with CNC Aluminum Alloy: Meticulously crafted from CNC aluminum alloy, the transmitter casing ensures efficient thermal conductivity. Coupled with an intelligently designed Heatsink system, optimal heat dissipation is achieved for prolonged usage.
- User-Friendly Design with Customizable Features: The transmitter boasts 2 customizable buttons and 1 USB port, accommodating external power sources. This design facilitates steadfast long-range expeditions, allowing pilots greater control and flexibility.
- Durable Construction for Long-lasting Performance: Built with durability in mind, the Gemini transmitter is designed to withstand the rigors of extended usage, making it a reliable choice for enthusiasts seeking high-performance capabilities in their radio control systems.
Based on ELRS V3.3 and collaborated with ELRS developer team, the First Ever Gemini Dual-Frequency Diversity Transmitter comes out! At present, SuperG Nano Transmitter can be fully activated to achieve the best link quality ever combined with diversity rx such as SuperD receiver or SuperP receiver. With dual 1W transmit power, it excels in anti-interference performance and stability, making it the ideal solution for demanding applications like FPV racing, long-range flight, and professional photography.
Specification
Item: BETAFPV SuperG Nano Transmitter Module | ELRS 2.4G
Weight: 44.8g
Color: Black, Red, Grey
Antenna Connector: 2* RP-SMA
RF Power: 25mw/50mW/100mW/250mW/500mW/1000mW
Packet Rate: 50Hz/100Hz/150Hz/250Hz/333Hz/500Hz/D250/D500/F500/F1000
Frequency Band: 2.4GHz ISM
Backpack: support
Input Voltage: 7V~13V DC
Rated Current: 8V,1000mA@1000mW, 1:128, Gemini mode
USB Port: Type-C
Fan Voltage: 5V
Default Firmware Version: ExpressLRS V3.3.0
Target Name: BETAFPV SuperG Nano 2.4GHz TX
Package
1 SuperG Nano Transmitter (Black/Red/Grey)
2 2.4G Glue Stick Antenna
1 USB to Type-C Data Cable
1 Type-C Male to XT30U Male Power Cable
1 GH1.25 Male to FUTABA Male Signal Cable
1 Micro-Nano Module Adapter (Standard Version)
1 Double Side EVA Foam Tape
1 Instruction Manual
1 Service Card
